How can I load balance UDP with open source HAProxy?

Spoiler alert: If you came here hoping open source HAProxy could load balance your UDP traffic out of the box, I’ve got bad news. The good news? You don't need an enterprise license to fix it. Linux Virtual Server (LVS) is sitting right in your kernel, ready to save the day—and setting it up is surprisingly painless. Here's your step-by-step workaround.

Why doesn't HAProxy support UDP?

Why? Well, to be honest, because it doesn't really make any sense! Why would you want a Layer 7 Reverse Proxy to support Layer 4 UDP routing? In the UNIX/Linux world, engineers have always used the right tool for the right job — and then you combine the tools together for the best result.

The best tool to use for UDP load balancing is LVS (Linux Virtual Server). LVS is an open source project that's been around for 30 years. It's integrated with the Linux kernel and used on millions of production networks. It's exactly what the commercial HAProxy ALOHA appliance uses, plus every other load balancer vendor I can think of.

Does UDP still matter when HTTP/3 QUIC is coming?

The new standard HTTP/3 QUIC combines UDP’s speed with added reliability, security, and efficiency. So yes, the traditional need for simple, fast UDP applications will be much reduced.

However, HTTP/3 is complex, evolving and very new. Most people haven't even moved to HTTP/2 yet, so somehow I think we will be living with UDP support requirements for several years to come :-).

OK, so what would you typically use UDP for?

UDP is a connectionless protocol, meaning it doesn't establish a formal connection or 'handshake' before sending data. It simply sends datagrams without any guarantee of delivery, order, or error correction. This makes it very fast and efficient, which is why it's used for applications where speed is more important than reliability, such as the following:

• Remote desktop and video and audio streaming
• Telecoms, VoIP and satellite
• Online gaming and multi-user broadcasts
• DNS, FTP & DHCP
• IoT, drones and robots

But if you are reading this, you probably already know exactly why you need it. So let's get on with how to do it.

How-to: A simple UDP load balancing configuration using LVS instead of HAProxy

You can run LVS and HAProxy on the same host with no issues, as they're very complementary. For this example, I'm going to assume that you have a working Rocky Linux environment.

This network diagram shows how you would deploy this in production, but I'm going to try and keep the example simple:

1. First, you need to install LVS, activate the module on boot and ensure that the Linux kernel will allow layer 4 routing:

sudo dnf install -y ipvsadm
echo "ip_vs" | sudo tee /etc/modules-load.d/ip_vs.conf
echo "net.ipv4.ip_forward = 1" | sudo tee /etc/sysctl.d/99-ipvs.conf
sudo sysctl -p /etc/sysctl.d/99-ipvs.conf

2. Then you need to configure the internal and external floating IPs for LVS to listen on:

sudo ip addr add 10.0.0.20/24 dev eth0 label eth0:0
sudo ip addr add 192.168.1.20/24 dev eth0 label eth0:1

3. Then use the ipvsadm user space tool to tell the kernel that LVS is going to handle traffic for this interface as a VIP (Virtual IP Address):

sudo ipvsadm -A -u 10.0.0.20:53 -s rr

4. Here we are specifically telling LVS to listen only for UDP packets on port 53 i.e. DNS. And we are going to load balance the packets in a simple round-robin rotation to the two backend servers (real servers):

sudo ipvsadm -a -u 10.0.0.20:53 -r 192.168.1.50:53 -m
sudo ipvsadm -a -u 10.0.0.20:53 -r 192.168.1.60:53 -m

5. Now, because we are using NAT mode load balancing, we need to make sure that both backend servers reply through the load balancer. The simplest way to do that is to configure both backend servers to use the load balancer as a default gateway:

sudo ip route replace default via 192.168.1.20

How do I see what is happening with the traffic?

LVS has good basic monitoring capabilities, but bear in mind that all the traffic is routed. A Layer 4 load balancer can only see connection information. You can't get detailed traffic inspection, logging and statistics as you would with HAProxy.

sudo ipvsadm -Ln --stats

IP Virtual Server version 1.2.1 (size=4096)
Prot LocalAddress:Port               Conns   InPkts  OutPkts  InBytes OutBytes
  -> RemoteAddress:Port
TCP  10.0.0.20:53                      10       60        0    5120        0
  -> 192.168.1.50:53                    5       30        0    2560        0
  -> 192.168.1.50:53                    5       30        0    2560        0

You can also use the SNMP module for LVS that Loadbalancer.org supports for the open source community. And yes, if you're interested, we've also open-sourced our HAProxy SNMP agent.

What about High Availability and health checks?

Ah well, like I said, Linux always has tools that you can combine for the desired result. Good options are solutions like Keepalived or HA-Linux + Ldirectord. And you can also easily write your own health check scripts.

You can find a much more detailed example of LVS + Keepalived here, and an overview of Keepalived on the LVS site. And finally, here's a very old but useful tutorial on LVS Keepalived & Ldirectord.
