Load balancing Microsoft Exchange

Updated on April 2, 2025
Published on March 8, 2023

About Microsoft Exchange

Microsoft Exchange Server, the mainstay of Microsoft’s Unified Communications solution, has grown beyond being regarded as the standard in business email into a fully-fledged communications tool. Exchange 2019 is Microsoft’s latest enterprise-level messaging and collaboration server – its architecture is very similar to Exchange 2016.

Key benefits of load balancing

Here are a few key benefits:

  • Ensures the application is always available
  • Provides a stable, optimal performance
  • Ability to isolate servers which reduces risk when performing upgrades/maintenance
  • Scalability

Microsoft’s Enterprise solutions are at the heart of businesses everywhere. Loadbalancer.org is officially certified for all of Microsoft’s key applications which you can find here. More details on the Microsoft Exchange components, how it works, and prerequisites for load balancing can be found in our deployment guide, available to view below.

How to load balance Microsoft Exchange

To implement highly available and scalable deployments of Microsoft Exchange Server, Microsoft recommends using a load balancer to distribute the traffic among multiple Exchange servers. Both current and legacy versions of Exchange support load balancing, with a different approach and recommendations dependent on the version you are running.

Example Exchange 2019 / 2016 deployment using a minimal 2 server setup.

The load balancer can be deployed in 4 fundamental ways: Layer 4 DR mode, Layer 4 NAT mode, Layer 4 SNAT mode and Layer 7 SNAT mode.

  • For Exchange 2019, 2016 or 2010 we recommend using Layer 7 SNAT mode for simplicity
  • For Exchange 2013, where possible we recommend Layer 4 Direct Routing (DR) mode

Exchange 2019, 2016 and 2013 Protocol Table

Protocol Role Ports Load balancing methods
TCP CAS 443 Used for Outlook on the Web, AutoDiscovery, Web Services, ActiveSync, Outlook Anywhere, Offline Address Book, Exchange Administration Center). Layer 4 DR (Direct Routing – Ultra-fast, local server based load balancing) Layer 7 SNAT
TCP CAS 25 Used for Inbound SMTP Layer 4 DR (Direct Routing – Ultra-fast, local server based load balancing) Layer 7 SNAT (Flexible, URL switching and cookie insertion capabilities)
TCP CAS 110,995,143,993 Used for POP3 clients Used for IMAP4 clients Layer 4 DR (Direct Routing – Ultra-fast, local server based load balancing) Layer 7 SNAT (Flexible, URL switching and cookie insertion capabilities)

Exchange 2010 Protocol Table

Protocol Role Ports Load balancing methods
TCP CAS 80 Layer 7 SNAT
TCP CAS 443 Layer 7 SNAT
TCP HT 25 Used for the HT (Hub Transport) role Layer 4 DR (Direct Routing – Ultra-fast, local server based load balancing) Layer 4 NAT (Fast Load balancing throughput) Layer 7 SNAT (Flexible, URL switching and cookie insertion capabilities)
TCP CAS 110, 995, 143, 993, 135, 60201 Used for POP3 clients Used for IMAP4 clients RPC endpoint mapper Static port for Exchange address book service Layer 7 SNAT
